2022 HydMech Group V18APC-60

2022 HydMech Group V18APC-60

$169,500 (USD)

with 40' in feed and 40' out feed Conveyor

Location:Colorado

orCall 1 501-897-1110

Description

Delivery: Terms: Net before Shipment F.O.B.: Standard Machine Features • Automatic programmable mitering with “go to” angle functionality from 60° left to 60° right • Four full stroking hydraulic vises (12″ h shuttle, 6″ h main, and 6″ h outboard) and h squaring vise • Automatic multi-indexing up to 40” in a single stroke. • Powered movable guide arm • Automatic PLC control programmable up to 1000 jobs with 5 in queue. • Hydraulic overhead bundling • 7.5 HP VFD. True direct blade drive – no belts/pulleys • Hydraulic DDF system • Blade chamber separates material from cut part • Out of stock switch • Cast iron band wheels • Replaceable blade brush • Robust steel base • Easy access electrical panel and hydraulics • Blade breakage switch • Drag chain chip conveyor • You choose left or right side infeed • Hydraulic band tensioning with digital readout • Replaceable carbide guide inserts • 2 HP hydraulic pump provides system pressure • Safety door interlocks • Flood coolant with wash down hose • Laser light and Work light • Variable vise pressure • 3 degree head cant Optional Machine Features • Blade mist lubrication system • Non-driven pop up lift roller • Powered conveyors

SPECIFICATIONS AND CONDITION ARE CORRECT TO THE BEST OF OUR KNOWLEDGE AND ARE SUBJECT TO YOUR VERIFICATION AND CORRECTION. THE CONDITION OF THE MACHINE IS AS IT HAS BEEN REPRESENTED TO US. ALL MACHINES ARE SUBJECT TO PRIOR SALE. EVERY MACHINE, UNLESS OTHERWISE SPECIFIED, IS OFFERED SUBJECT TO OUR GUARANTEE THAT IF FOUND TO BE MECHANICALLY UNSATISFACTORY WITHIN 30 DAYS AFTER SHIPMENT, SAME MY BE RETURNED, FREIGHT PREPAID FOR FULL CREDIT OR REPAIRED AT DEALER’S OPTION. ALL MACHINES RETURNED TO US MUST BE IN AS GOOD A CONDITION AS WHEN SHIPPED.

Specifications

ManufacturerHydMech Group
ModelV18APC-60
Year2022
ConditionUsed
CapacityRectangular (w x h) Round
90°18" x 22" 18"
45°18" x 14.75" 13"
30°18" x 9" 9"
90° with oh bundling18" x 12" 12"
45° with oh bundling18" x 12" 12"
30° with oh bundling18" x 6" 6"
Blade size1.25” x 16’ 11”
Blade drive7.5 HP VFD
Motor voltage208, 240, 480 v
Blade speed65-385 SFM
Coolant tank capacity30 Gallons
Hyd. tank capacity8 Gallons
Machine weight9,000 lbs.
Table height44”
Dimensions (w x l x h)120” x 188” x 112”
Mitering capability60° left to 60° right
