2020 HydMech Group S-23P

2020 HydMech Group S-23P
$22,500 (USD)
Little Rock, AR
Description
Delivery: TBD Terms: Net before Shipment F.O.B.: Little Rock, Arkansas Standard Machine Features • Semi-automatic PLC control • Easy swing, heavy duty cast iron saw head that can swing up to 60 degrees in one direction. • Full capacity, full stroking hydraulic vise • 8.8 HP VFD True direct blade drive – no belts/pulleys • On-demand hydraulics save energy • 19.75” out feed table and 43″ infeed table • Blade breakage switch • Cast iron band wheels • Replaceable blade brush • Robust steel base • Easy to read angle scale with angle locking mechanism • Cast iron guide arms. Idler side guide arm is adjustable and supported by linear rail. • Easy access electrical panel • Hydraulic positive down feed sawing head with infinite down feed adjustments • Mechanical band tensioning with digital readout • Pre-set replaceable carbide guide inserts • Safety door interlocks • Flood coolant with wash down hose • Laser light • Work light • Variable vise pressure Optional Machine Features • Full capacity hydraulic overhead bundling • Idler conveyors • Work stop SPECIFICATIONS AND CONDITION ARE CORRECT TO THE BEST OF OUR KNOWLEDGE AND ARE SUBJECT TO YOUR VERIFICATION AND CORRECTION.
Specifications
Manufacturer | HydMech Group |
Model | S-23P |
Year | 2020 |
Condition | Used |
Stock Number | 00024 |
Capacity | Rectangular (h x w) Round |
90° | 16" x 20" 16" |
45° | 16" x 14" 14" |
30° | 16" x 9.5" 9.5" |
Blade size | 1.25" x 16'10" |
Blade drive | 8.8 HP VFD |
Machine voltage | 480 |
Blade speed | 75-350 SFM |
Coolant tank capacity | 9 Gallons |
Work load | 5,000 lbs. |
Machine weight | 2,900 lbs. |
Table height | 33” |
Dimensions (w x l x h) | 96” x 80” x 56” |
