HANS LASER (NEW) FIBER LASER

HANS LASER (NEW) FIBER LASER

Contact us for price

Location:Little Rock, AR

orCall 1 501-897-1110

Description

HANS LASER (NEW) MODEL 4020F FIBER LASER 4 KW IPG 6′ X 12′ BED (4000 MM X 2000 MM) 4 KW IPG FIBER RESONATOR WITH WATER CHILLER 393’/MINUTE MAXIMUM AXIS SPEED 1 G FORCE 2,866 LB WEIGHT CAPACITY (1300 KG) 19,840 MACHINE TOOL WEIGHT (9000 KG) 159″ X AXIS (4050 MM) 79.9″ Y AXIS (2030 MM) 9.8″ Z AXIS (250 MM) +/- 0.0012 X AND Y AXIS POSITION ACCURACY (.03 MM) +/- 0.0008 X AND Y AXIS REPEATABILITY (0.02 MM) TABLES – TWIN PALLETS SANYO DRIVE SYSTEM HELICAL RACK-PINION HANS 701 PRO-A CONTROL METALIX CNC KAD PROGRAMMING AND NESTING SOFTWARE CLASS 1 FDA CERTIFIED 2 YEAR WARRANTY – PARTS & LABOR OPTIONS AVAILABLE – PRICE ON REQUEST – 2, 3, AND 6 KW IPG FIBER RESONATORS – AIR COMPRESSOR SYSTEM UPGRADE – DONALDSON DUST COLLECTOR – GAS MIXER FOR ALUMINUM CUTTING – AUTO LOAD-UNLOAD SYSTEMS – OVER/UNDER CARTS GANTRY SYSTEM 10-SHELF TOWER – WORK LIFTERS UNDER PALLET – ADDITIONAL METALIX SOFTWARE SEAT – METALIX DRAG AND CUT SOFTWARE MODULE – METALIX SOFTWARE TRAINING – UL LISTING CERTIFICATE FOR AUTOMATION – UL LISTING CERTIFICATE FOR LASER SPECIFICATIONS AND CONDITION ARE CORRECT TO THE BEST OF OUR KNOWLEDGE AND ARE SUBJECT TO YOUR VERIFICATION AND CORRECTION. THE CONDITION OF THE MACHINE IS AS IT HAS BEEN REPRESENTED TO US. ALL MACHINES ARE SUBJECT TO PRIOR SALE. EVERY MACHINE, UNLESS OTHERWISE SPECIFIED, IS OFFERED SUBJECT TO OUR GUARANTEE THAT IF FOUND TO BE MECHANICALLY UNSATISFACTORY WITHIN 30 DAYS AFTER SHIPMENT, SAME MY BE RETURNED, FREIGHT PREPAID FOR FULL CREDIT OR REPAIRED AT DEALER’S OPTION. ALL MACHINES RETURNED TO US MUST BE IN AS GOOD A CONDITION AS WHEN SHIPPED.

Specifications

Model4020F 6 x 12
ConditionNew
